VBOX-3630

In-Vehicle Computer for On-board Telematics

Intel® 11th Gen Core™ i7-1185G7E CPU with 4 x GbE LAN On-Board Mobile Computer for Fleet

Product Status: Available

Inquiry Datasheet

Features

Intel® 11th Gen Core™ i7-1185G7E
Supports Dual 5G / LTE, GPS, Wi-Fi / BT, and CAN Bus Modules
Wide Range Input 9V – 60VDC with Ignition Control for EV Installations
1 x 2.5GbE + 3 x GbE LAN Port with M12X Connectors
Supports 4 Independent Display Outputs: 2 x HDMI®, 1 x DP, 1 x DVI-D
Supports Optional Battery Backup Kit
E-Mark & EN50155 Certified

Introduction

VBOX-3630 is a fanless in-vehicle computer with 5G connectivity. It utilizes Intel® 11th Gen Core™ i7-1185G7E CPU up to 4.4GHz. VBOX-3630 features an ultra-compact design measuring 250 x 165 x 55mm, which can easily fit into restricted spaces. The system can select 5G, LTE, GPS, and Wi-Fi / Bluetooth as robust connectivity by M.2 modules. It is a building-in four independent display output, audio line-out, and microphone-in. It is the perfect solution for fleet management, in-vehicle digital signage, and mobile DVR. Furthermore, it features Smarter Vehicle Power Ignition and wireless remote control in various vehicles.VBOX-3630 can effectively support cars in extreme weather and operating conditions, such as snowplows, trucks, buses, taxis, and forklifts.

SYSTEM

Processor

Intel® 11th Gen Core™ i7-1185G7E 1.8GHz up to 4.4GHz
Intel®11th Gen Core™ i5-1145G7E 1.5GHz up to 4.1GHz
Intel® 11th Gen Core™ i3-115G4E 2.2GHz up to 3.9GHz
Intel® Celeron® 6305E up to 1.8GHz

Memory

2 x DDR4-3200 SO-DIMM Up to 64GB

Watchdog

Watchdog Timer Support, Offer 1 – 255 Step

TPM

2.0

GRAPHICS

Graphics Engine

Intel® Iris® Xe Graphics / Intel® UHD Graphics

HDMI®

DisplayPort

DVI

1 (Supports 4 Independent Display)
*Use only Single Link DVI Cables.

VGA

N/A

Resolution

Max Resolution (HDMI® 2.0b): 4096 x 2304@60Hz
Max Resolution (DP): 4096 x 2304@60Hz

AUDIO

Audio Codec

N/A

Line-out

Mic-in

Line-in

Optional

ETHERNET

LAN Chipset

1 x Intel® 2.5GbE Supports 10/100/1000/2500BASE-T supports vPro and PXE LAN Boot ROM (i5/i7 SKU)

3 x Intel® Gigabit Ethernet

LAN

4 x RJ45 or 4 x M12 X-coded (1 x 2.5GbE, 3 x GbE)

I/O

Serial Port

4 x RS-232/422/485
(Auto Direction Control)

(*3 Ports for M12 Model)

USB Port

2 x USB 3.2 Gen 2 (10 Gbps)
2 x USB 2.0

DIO

6 x DI (5~60V) and 4 x DO (5V/100mA)
2 x DC Output (12V/1A )

SIM Socket

2 x SIM Card Sockets Supported Onboard with Eject

Antenna

10 x Pre-cut Holes for External SMA Antenna

STORAGE

SSD/HDD

2 x 2.5″ Drive Bay for SATA Type support RAID 0,1

mPCIe

N/A

mSATA

N/A

M.2

1 x M.2 2280 Key M for NVMe SSD

EXPANSION

mPCIe

2 x mPCIe
(*One is shared with M.2 Key B)

M.2

1 x M.2 2230 Key E
2 x M.2 3042/52 Key B

POWER

Power Input

9~60 VDC Input
(24 ~ 60 VDC Input for VBOX-3630P-M12X)

Power Protection

Automatics Recovery Short Circuit Protection

Smart Ignition

Power Ignition for Vehicle

Power-off Delay Control

Power off Delay Time Setting by Software

Backup Battery Solution

Internal Battery Kit for 10 Mins Operating
*Patent No.: M447854 – Build-in Battery

MECHANICAL

Dimension

250(L) x 165(W) x 55(H) mm

Weight

2500g (barebone)

Construction

Aluminum Alloy

Mounting

Wall-mount

ENVIRONMENT

Relative Humidity

10% RH – 90% RH (non-condensing)

Operating Temp.

-40°~ 70°C, ambient w/ 0.6m/s airflow
Patent No. M448011-Thermal Cooling

Storage Temp.

-40° ~ 85°C

Vibration & Shock

IEC60068-2-64, random, 2.5G@5~500Hz, 1hr/axis
MIL-STD-810G, Method 514.6, Procedure 1, Cat.4, Operating

Operating: MIL-STD-810G, Method 514.6, Procedure 1, Trucks and semi-trailers 15G (11m with SSD)

CERTIFICATION

Certification

CE, FCC Class A, E-Mark, EN50155, EN45545-2 (R25)

OPERATIONAL SYSTEM

Windows

Windows 10 IoT LTSC (64-bit)
Windows 11 IoT (64-bit)

Linux

Ubuntu 20.04 (64-bit), 22.04 (64-bit)

ORDERING INFORMATION

Model No.

VBOX-3630x-yyyy-zz (x=P=w/PoE, yyyy= M12X=M12 x-code for LAN ports, zz=i7=i7-1185G7E, zz=i5=i5-1145G7E, zz=i3=i3-1115G4E, zz=C1=6305E)

Description

Intel® 11th Gen Core i7-1185G7E CPU with 4 x GbE LAN On-Board Computer

State of Origin

Made in Taiwan

Optional Accessories

DRAM

DDR4 SO-DIMM 3200 8GB~32GB (-40~85) x 2

SSD

2.5 inch SATA SSD TLC 64GB~1TB (-40~85°C)

M.2 2280 NVMe 256GB~1TB TLC (-40~85°C)

Wi-Fi Module

M.2 2230 Wi-Fi 6E + Bluetooth 5.2 Module

WWAN Modem

M.2 3042/52 5G/LTE Modem

GPS

mPCle GPS Module

CAN Bus

mPCle CAN Bus Module

Battery Backup Kit

BAT-3630 Kit, 2,300mAh 3S1P Battery Kit (0~60°C for Discharge)
